8oz. TTVJ Vinyl Zyme Extra Strength record cleaning solution included with purchase!
Cleaning fluid is applied to the rotating record surface and manually brushed into the grooves of the record to agitate dirt and contaminants. The vacuum arm traverses across the record producing a powerful vortex vacuum which effortlessly extracts the contaminated waste fluid out of the record grooves which is deposited into the external waste jar.
The PRC4i is equipped with a double-ended pump system which provides an impressive suction capacity of 28 litres per minute. With a pump mounted at either end of the vacuum motor it delivers a high vacuum performance whilst emitting a lovely balanced sound. The new double pump design ensures that even heavily contaminated or warped records will be thoroughly cleaned.
The main spindle and bearing are precision made and housed in a robust phosphor bronze case to make good use of the high torque motor. Bearing spindle and motor are designed for long life and importantly provide a considerable drive force to the platter to aid the cleaning process. The cleaning vacuum arm has precision horizontal and vertical yoke bearings for precise arm movement and is driven across the vinyl record by a custom made gearing system. The vacuum arm yoke bearings are the highest grade and designed to prevent ingress contamination from cleaning fluids. The platter can rotate in forward (clockwise) and reverse (anti-clockwise) directions for thorough cleaning of the record grooves, a unique feature as dirt can be driven into the record grooves by a playing stylus. Cleaning in both directions of the groove provides optimum cleaning performance.
Standard Features:
Very quiet in operation, forward and reverse platter rotation
Designed for 7, 10, 12 & 16 inch records
Record ready to play straight after cleaning
Clean and dry in less than two minutes per record side
Brush designed to work cleaning fluid into the grooves, loosening contaminants
Suction vortex generated between nozzle and record surface for efficient vacuum cleaning
Soiled cleaning fluid and contaminants extracted and collected in transparent waste jar
A bottle of L’Art du Son concentrate and an application brush is included, enough to clean about 1000 LPs
Improved Features:
Cabinet
CNC machined cabinet with hand finished natural wood veneer
High density internal noise absorption material
Integrated waste fluid bottle holder
Refreshed fascia panel
Vacuum System
Handcrafted vacuum arm – black finish
Vacuum nozzle design improved for better vortex and suction performance
Vacuum pump noise level reduced
Automatic cleaning thread advance
Drive System
Precision spindle bearing, oil charged for smoother operation
Close tolerance main bearing and robust housing case
Material specification and revised finishes
Specifications:
Versions: Europe 230v, USA 115v and Japan 100v (Japan version switchable for 50/60Hz)
Dimensions: W: 550mm D: 410mm H: 273mm
Weight: 15kg (unit only)
